Product detail
On-line catalogue
9141390, starter motor
| Item | Value |
|---|---|
| Product | starter motor |
| Magneton code | 9141390 |
| Rated Voltage | 12 V |
| Rated power | 1.7 kW |
| rated speed | 1500 ot/min |
| Starting point | 20 Nm |
| Number of pinion teeth | 10 |
| module | 2.1167 |
| Angle of View | 81; 198; 324 ° |
| Weight | 3 kg |
| Image |
|
| Mark and Model | Engine | Volume [l] | Power [kW] | Date of manufacture | Application |
|---|---|---|---|---|---|
| VW California 1.8 | PD | 1.8 | 48 | 01.12.1990 - 01.07.1992 | passenger car |
| VW California 2.0 | AAC | 2 | 62 | 01.09.1990 | passenger car |
| VW Caravelle 1.8 | PD | 1.8 | 48 | 01.12.1990 - 01.07.1992 | passenger car |
| VW Caravelle 2.0 | AAC | 2 | 62 | 01.09.1990 | passenger car |
| VW Multivan 1.8 | PD | 1.8 | 48 | 01.12.1990 - 01.07.1992 | passenger car |
| VW Multivan 2.0 | AAC | 2 | 62 | 01.09.1990 | passenger car |
| VW Transporter 2.0 | AAC | 2 | 62 | 01.09.1990 | passenger car |
| VW Transporter 2.0 | PD | 1.8 | 48 | 01.12.1990 - 01.07.1992 | passenger car |
| Manufacturer | Original number |
|---|---|
| BOSCH | 0001108097 |
| BOSCH | 0986016750 |
| BOSCH | 0001108096 |
| DELCO REMY | DRS6750 |
| VW | 02B911023BX |
| VW | 02B911023B |
| Component Name | Part number |
|---|---|
| Armature assy | 7150.882 |
| Assembled contactor | 7150.872 |
| Bearing | 324 137 038 |
| Bearing | 324 165 006 |
| Front cover | 1655.160 |
| Pinion drive | 7153.580 |
| Rear cover | 1658.400 |
| Stator with holder | 7155.351 |
| Transmission cover | 6954.940 |
