9141331, starter motor
| Item | Value |
|---|---|
| Product | starter motor |
| Magneton code | 9141331 |
| Rated Voltage | 12 V |
| Rated power | 1 kW |
| rated speed | 1500 ot/min |
| Starting point | 15 Nm |
| Number of pinion teeth | 9 |
| module | 2.1167 |
| Angle of View | 30; 111; 242 ° |
| Weight | 3 kg |
| Image |
|
| Mark and Model | Engine | Volume [l] | Power [kW] | Date of manufacture | Application |
|---|---|---|---|---|---|
| SEAT Arosa 1.0 | AHT | 1 | 37 | 01.10.1997 | passenger car |
| SEAT Arosa 1.0 | AER | 1 | 37 | 01.02.1997 | passenger car |
| SKODA FABIA 1.4 (6Y2) | AME | 1397 | 50 | 01.09.1999 | passenger car |
| SKODA FABIA 1.4 (6Y2) | AQW | 1397 | 50 | 01.09.1999 | passenger car |
| SKODA FABIA 1.4 (6Y2] | ATZ | 1397 | 50 | 01.09.1999 | passenger car |
| SKODA FABIA 1.4 (6Y3) | AME | 1397 | 50 | 01.06.2001 | passenger car |
| SKODA FABIA 1.4 (6Y3) | AQW | 1397 | 50 | 01.07.2001 | passenger car |
| SKODA FABIA 1.4 (6Y5) | AQW | 1397 | 50 | 01.11.2000 | passenger car |
| SKODA FABIA 1.4 (6Y5) | AME | 1397 | 50 | 01.11.2000 | passenger car |
| SKODA FABIA 1.4 (6Y5) | ATZ | 1397 | 50 | 01.11.2000 | passenger car |
| SKODA OCTAVIA 1.4 (1U2) | AMD | 1397 | 44 | 01.04.1999 | passenger car |
| Manufacturer | Original number |
|---|---|
| REAL | 20488000 |
| SKODA AUTO | 047911023G |
| SKODA AUTO | 047911023C |
| VW | 047911023G |
| VW | 047911023C |
| Component Name | Part number |
|---|---|
| Armature assy | 7150.882 |
| Assembled contactor | 7152.822 |
| Bearing | 324 137 038 |
| Bearing | 324 165 006 |
| Front cover | 1655.080 |
| Pinion drive | 7152.960 |
| Rear cover | 6956.040 |
| Stator with holder | 7153.461 |
| Transmission cover | 6955.830 |
